Specifications
Pump connection 4-pin
Minimum airflow 29.46 cfm
Type air cooling
Fan speed (min) 600 RPM
Fan diameter 12 cm
Mean time to failure (MTTF) of the pump 80000 h
Maximum airflow 69.63 cfm
Minimum air pressure 0.36 mmH2O
Noise level (high speed) 25 dB
Fan speed (max) 1600 RPM
Recommended placement processor
Maximum air pressure 1.39 mmH2O
Design
Product color black
Fin material aluminum
Number of heat pipes 6
Base material copper
Energy Thermal Design Power (TDP) 280 W
Fan voltage 12 V
Fan current 0.19 A
Weight and dimensions
Blower dimensions (W x D x H) 120 x 120 x 25 mm
Weight 1.01 kg
Depth 134 mm
Heat pipe diameter 6 mm
Width 120 mm
Height 159 mm
